MADE IN ITALY since 1972

HP 2000
HP 2000 C
HP 140-175

hp2000New2
1) HP 2000, HP 140-175
2) HP 2000 C

Features:
HP 2000: Ground plane independent
Versions "For Middle East only" are manufactured according to Saudi standards. Please see PRODUCT MANUAL "Id-100_MO..." below

Product Number:
P/N: 2210105.05 HP 2000
P/N: 2210205.05 HP 2000 C
P/N: 2213405.05 HP 140-175
Electrical Data:
Type: HP 2000: 1/2 λ
HP 140-175: 5/8 λ
HP 2000 C: C-loaded
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range:
HP 2000:
142–149 MHz No tuning required
HP 2000 C:
137–157 MHz No tuning required
HP 140-175:
139.3 … 175 MHz Tunable
Systems: 2m-HAM, VHF Marine Band, ORBCOMM M2M, ISM-169MHz
Gain: HP 2000, HP 140-175: 1.5 dB ref. to a λ/4 whip
HP 2000 C: 2 dB ref. to a λ/4 whip
Max Power: 150 W (CW)
Grounding protection: DC-Ground
Connector: UHF-male (PL-259)
Mechanical Data:
Materials: Chromed brass, Stainless Steel 17/7 PH, Nylon
Height (approx):
HP 2000:
1060 mm / 3.48 ft
HP 2000 C:
1410 mm / 4.63 ft
HP 140-175:
1435 mm / 4.71 ft
Weight (approx): 320 gr / 0.71 lb
Mounting type: On-Connector
Suitable Accessories:
Magnetic Mount: PM-100 PL (P/N:2502502.05)
Magnetic Mount: PM 125 PL (P/N:2502602.05)
Cable: HP-AC/U Angular Connector (P/N:2510805.00)
