SIGNAL KEEPER

Product Number:
2101301.00 SIGNAL KEEPER
Electrical Data:
Type: 1/4 λ base loaded ground plane
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range: 26-28 MHz No tuning required
Systems: 10m-HAM
Gain: 0 dBd, 2.15 dBi
Bandwidth: ≥ 850KHz @ SWR ≤ 2
Max Power: 100 Watts (CW) continuous
300 Watts (CW) short time
Connector: UHF-female (SO-239)
Mechanical Data:
Materials: Aluminium, Chromed brass, Stainless steel, Nylon, Zamak
Height (approx): 2370 mm / 7.78 ft
Weight (approx): 640 gr / 1.41 lb
Mounting type: On-Mast
Suitable Accessories:
Bracket: FT-2
