Product Number:
2209706.26/1090	SKB 1090 960-1164 ML/5M RG58/SMA-M Included: Hole mount: ML
2209706.75/1090	SKB 1090 1/4 MAG/3M RG58 SMA-M Included: Magnetic Mount: CELL-MAG (P/N:2510202.00)

Electrical Data:
Type:	1/4 λ
Radiation:	Omnidirectional
Polarization:	Linear vertical
Frequency range:	1090 MHz
Systems:	ADS-B-1090MHz
Gain:	0 dB ref. to a λ/4 whip
Max Power:	30 W (CW)
Cable lenght / type:	SKB 1090 960-1164 ML/5M RG58/SMA-M: 5 m (16.4 ft) / RG58 SKB 1090 1/4 MAG/3M RG58 SMA-M: 3 m (9.84 ft) / RG58
Connector:	SMA-male

Mechanical Data:
Materials:	Chromed brass, Stainless steel, Siliconic rubber
Height (approx):	SKB 1090 960-1164 ML/5M RG58/SMA-M: 82 mm / 0.27 ft SKB 1090 1/4 MAG/3M RG58 SMA-M: 87 mm / 0.29 ft
Weight (approx):	SKB 1090 960-1164 ML/5M RG58/SMA-M: 240 gr / 0.53 lb SKB 1090 1/4 MAG/3M RG58 SMA-M: 220 gr / 0.49 lb
Mounting type:	SKB 1090 960-1164 ML/5M RG58/SMA-M: Thru-Hole SKB 1090 1/4 MAG/3M RG58 SMA-M: Magnetic mount

Suitable Accessories:
Magnetic Mount: CELL-MAG (P/N:2510202.00)
