Product Number:
2113020.00	SPO 868-8 Included: Bracket: FT-5
2112120.00	SPO 868-10 Included: Bracket: FT-5

Electrical Data:
Type:	Colinear
Radiation:	Omnidirectional
Polarization:	Linear vertical
Frequency range:	868 - 870MHz @ SWR ≤1.3 No tuning required
Systems:	ISM/SIGFOX/LoRa 868MHz
Gain:	SPO 868-8: 5.9 dBd - 8.0 dBi SPO 868-10: 8.4 dBd-10.5 dBi
Max Power:	20 W (CW)
Connector:	N-female

Mechanical Data:
Materials:	Aluminium, Anodized Aluminium, Nickel plated brass, Stainless steel, Fiberglass, PCB
Height (approx):	SPO 868-8: 1600 mm / 5.25 ft SPO 868-10: 2590 mm / 8.5 ft
Weight (approx):	SPO 868-8: 1020 gr / 2.25 lb SPO 868-10: 1500 gr / 3.31 lb
Mounting type:	On-Mast
